ENGINE, DURAMAX 6.6L TURBO-DIESEL V8

B20-Diesel compatible (470 hp @ 2800 rpm 975 lb-ft of torque @ 1600 rpm)

• Rear axle
• 3.73 ratio (Requires (L8T) 6.6L V8 gas engine. Not available with (L5P) Duramax 6.6L Turbo-Diesel V8 engine.)
• Durabed
• pickup bed
• GVWR
• 11
• 025 lbs. (5001 kg)
• Air filter
• heavy-duty
• Air filtration monitoring
• Hill Descent Control
• Transfer case
• two-speed active electronic Autotrac with push button control
• Rear electronic locking differential
• Four wheel drive
• Cooling
• external engine oil cooler
• Cooling
• auxiliary external transmission oil cooler
• Battery
• heavy-duty 720 cold-cranking amps/80 Amp-hr maintenance-free with rundown protection and retained accessory power (Included and only available with (L8T) 6.6L V8 gas engine.)
• Alternator
• 170 amps (Requires (L8T) 6.6L V8 gas engine.)
• Trailer brake controller
• integrated
• Skid Plates
• ZR2
• Frame
• fully-boxed
• hydroformed front section and a fully-boxed stamped rear section
• Recovery hooks
• front
• frame-mounted
• Red
• ZR2 Suspension Package High-Performance lifted suspension with Multimatic DSSV dampers
• Steering
• Digital Variable Steering Assist this system automatically adjusts steering based on speed
• road conditions
• and other inputs to reduce driver effort and fatigue
• Brakes
• 4-wheel antilock
• 4-wheel disc with DURALIFE rotors
• Brake lining wear indicator
• Capless Fuel Fill (Requires (L8T) 6.6L V8 gas engine.)
• Exhaust
• single
• side
• Tires
• LT305/70R18-126/123R
• 35" Goodyear Territory MT
• Tire
• spare
• LT305/70R18-126/123R
• 35" M/T
• Wheel
• 18" aluminum spare
• Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door
• Bumper
• front (High gloss black.)
• Bumper
• rear (High gloss black.)
• CornerStep
• rear bumper
• BedStep
• Black integrated on forward portion of bed on driver and passenger side
• Moldings
• beltline
• Black
• Wheelhouse liners
• rear
• Cargo tie downs (12)
• fixed rated at 500 lbs per corner
• Power outlet
• bed mounted
• 120-volt (400 watts shared with (KI4) interior power outlet)
• IntelliBeam
• automatic high beam on/off
• Taillamps
• LED with signature
• animated
• Lamps
• cargo area
• cab mounted integrated with center high mount stop lamp
• with switch in bank on left side of steering wheel
• LED Cargo Area Lighting located in pickup bed
• activated with switch on center switch bank or key fob
• Fog lamps
• front
• LED
• Lamps
• Smoked Amber roof marker
• (LED) (Not available with (YF5) California state emissions requirements.)
• Mirrors
• outside power-adjustable vertical trailering with heated and auto-dimming upper glass
• (driver and passenger) lower convex mirrors
• turn signal indicators
• puddle lamps
• (U12) perimeter lighting
• auxiliary lighting
• power folding/extending (extends 3.31" )
• Mirror caps
• high-gloss Black
• Glass
• deep-tinted
• Wipers
• front rain-sensing
• Tailgate
• Multi-Flex with six functional load/access features
• NOTE: Auto release can be disabled if ball hitch is installed. See Owner's manual for details
• Tailgate and bed rail protection cap
• top
• Tailgate
• gate function manual with EZ Lift includes power lock and release (Required and only available with (QK2) Multi-Flex tailgate.)
• Door handles
• high gloss Black
• Steering wheel audio controls
• Seat adjuster
• driver 10-way power including lumbar
• Seat adjuster
• passenger 10-way power including lumbar
• Driver memory recalls driver "presets" for power driver seat and outside mirrors
• Seats
• heated second row outboard seats
• Seat
• Up-level Rear with Storage Package 60/40 Split rear seat with center armrest
• right
• and left seat back storage
• and under seat jack storage (Crew Cabs Only) Rear seat leather appointed (Rear seat features leather seating surfaces.)
• Center Console
• floor-mounted with cup holders
• cell phone storage
• power cord management
• hanging file folder capability
• Floor covering
• color-keyed carpeting
• Steering wheel
• wrapped
• Steering wheel
• heated
• Steering column
• manual tilt and telescoping
• Driver Information Center
• enhanced
• 12.3" diagonal reconfigurable multicolor digital display
• Exterior Temperature Display located in radio display
• Compass located in instrument cluster
• Rear seat reminder
• Window
• power front
• drivers express up/down
• Remote vehicle starter system
• Universal Home Remote
• Theft-deterrent system
• unauthorized entry
• Wireless Charging (Not compatible with all phones. Compliant batteries include QI and PMA technologies. Reference Mobile devices manual to confirm what type of battery it uses.)
• USB ports
• rear
• dual
• charge-only
• Power outlet
• interior
• 120-volt (400 watts shared with (KC9) bed mounted power outlet)
• Assist handles front A-pillar mounted for driver and passenger
• rear B-pillar mounted
• Chevrolet Connected Access capable (Subject to terms. See onstar.com or dealer for details.)
• StabiliTrak stability control system with Proactive Roll Avoidance and traction control
• includes electronic trailer sway control and hill start assist
• Airbags
• dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Front and Rear Park Assist
• Ultrasonic
• Bed View Camera camera in the CHMSL to show a view of the cargo bed
• display located in infotainment screen
• includes Two Trailer Camera Provisions
• TRAILER CAMERA PROVISIONS AND TRAILER VIEWING SOFTWARE
• Hitch Guidance dynamic single line to aid in trailer alignment for hitching
• In-vehicle Trailering App
• System includes checklist
• trailer maintenance reminders
• trailer security alerts
• trailer mileage
• tow/haul reminder
• trailer electrical diagnostics and Trailer Tire Pressure Monitor System module
• Rear Cross Traffic Alert
• Trailer Side Blind Zone Alert
• Lane Departure Warning
• Following Distance Indicator
• Seat Belt Adjustable Guide Loops
• front row only
• Buckle to Drive prevents vehicle from being shifted out of Park until driver seat belt is fastened; times out after 20 seconds and encourages seat belt use
• can be turned on and off in Settings menu
• Rear Seat Belt Indicator
• Safety Alert Seat
• Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob
• to help encourage safe driving behavior. It can limit certain available vehicle features
• and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Cold Cranking Amps @ 0° F (Primary): 720
• Cold Cranking Amps @ 0° F (2nd): 730
• Maximum Alternator Capacity (amps): 170
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Rear (lbs): 6600
• Curb Weight - Front (lbs): 4013
• Curb Weight - Rear (lbs): 2812
• Gross Vehicle Weight Rating Cap (lbs): 11025
• Gross Combined Wt Rating (lbs): 26000
• Gross Combined Wt Rating (lbs): 24500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 18500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 16000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1850
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1600
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 18100
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4525
• Maximum Trailering Capacity (lbs): 18500
• Suspension
• Suspension Type - Front: Short/Long Arm
• Suspension Type - Rear: Multi-Leaf Springs
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: - TBD -
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Stabilizer Bar Diameter - Front (in): 1.38
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.0 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14.1 x 1.3
• Tires
• Front Tire Order Code: QMG
• Rear Tire Order Code: QMG
• Spare Tire Order Code: QNZ
• Front Tire Size: LT305/70R18
• Rear Tire Size: LT305/70R18
• Spare Tire Size: LT305/70R18
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 18 x - TBD -
• Rear Wheel Size (in): 18 x - TBD -
• Spare Wheel Size (in): 18 x - TBD -
• Front Wheel Material: - TBD -
• Rear Wheel Material: - TBD -
• Spare Wheel Material: - TBD -
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 52.7
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 36
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 159
• Length, Overall (in): 250.04
• Width, Max w/o mirrors (in): 81.85
• Height, Overall (in): 82.68
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): 42.36
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 11.61
• Ground Clearance, Rear (in): 11.61
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 82.25
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 71.4
• Cargo Box Width @ Wheelhousings (in): 50.55
• Cargo Box (Area) Height (in): 21
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 69.5
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 43.03
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61.18
• Second Head Room (in): 40.12
• Second Leg Room (in): 43.4
• Second Shoulder Room (in): 65.3
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: Chevrolet Silverado 2500HD
• Body Style: Crew Cab Pickup
• Body Code: E63
